Baumer VCXG Series - Vcxg;.XC;.I;.I.xt;.Ptp;.I.ptp

V4.7 | 06/24/2024 | 11165414
70
On Baumer CX cameras, the exposure time can be set within the following ranges (step
size 1 μsec):
7.3.12.1 VCXG /.XC / .I / .I.XT / .PTP / .I.PTP
Camera Type
t
exposure
min
*
[μsec]
Release1.1׀Release2.0׀Release2.1׀Release2.2
׀Release3.0׀Release4.0|Release4.1
t
non-selectable range
1)
ExposureTimeGapMin - Exposure-
TimeGapMax
t
exposure
max
[sec]
Monochrome
VCXG-02M 20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-04M
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-13M / .I/.I.XT
20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-13NIR
x ׀ x ׀ x ׀ x ׀ 20 ׀ x 1
VCXG-14SWIR.XC
x ׀ x ׀ x ׀ x ׀ x ׀ x | 20 60
VCXG-15M / .I/.I.XT
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-22M.R
x ׀ x ׀ x ׀ 15 ׀ x ׀ x 60
VCXG-23M
35 ׀ 35 ׀ 35 ׀ x ׀ 35 ׀ x 60
VCXG-24M
57 ׀ 57 ׀ 57 ׀ x ׀ 57 ׀ x 60
VCXG-25M / .I/.I.XT
20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-32M / .I/.I.XT/.PTP/.I.PTP
50 ׀ 50 ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-50MP
x ׀ x ׀ x ׀ 1 ׀ x ׀ x 60
VCXG-51M / .XC / .I/.I.XT/.PTP/.I.PTP
43 ׀ 43 ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-53M / .I/.I.XT
20 ׀ 20 ׀ 20 ׀ x ׀ x 1
VCXG-53NIR
x ׀ x ׀ x ׀ x ׀ 20 ׀ x 1
VCXG-65M.R
x ׀ x ׀ x ׀ x ׀ 21 ׀ x 60
VCXG-82M / .I/.I.XT
x ׀ x ׀ x ׀ x ׀ x ׀ 1 4 - 22 μs 60
VCXG-91M
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-124M / .I/.I.XT/.PTP/.I.PTP
60 ׀ 60 ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-125M.R
x ׀ x ׀ x ׀ 85 ׀ 85 ׀ x 60
VCXG-127M / .I/.I.XT
x ׀ x ׀ x ׀ x ׀ x ׀ 1 4 - 30 μs 60
VCXG-201M.R / .I/.I.XT
x ׀ x ׀ x ׀ 115 ׀ 115 ׀ x 60
VCXG-204M
x ׀ x ׀ x ׀ x ׀ x ׀ 1 4 - 33 μs 60
VCXG-241M / .I/.I.XT
x ׀ x ׀ x ׀ x ׀ 39 ׀ 1 4 - 38 μs 60
Color
VCXG-02C 20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-04C
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-13C / .I/.I.XT
20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-15C / .I/.I.XT
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-22C.R
x ׀ x ׀ x ׀ 15 ׀ x ׀ x 60
VCXG-23C
35 ׀ 35 ׀ 35 ׀ x ׀ 35 ׀ x 60
VCXG-24C
57 ׀ 57 ׀ 57 ׀ x ׀ 57 ׀ x 60
VCXG-25C / .I/.I.XT
20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-32C / .I/.I.XT/.PTP/.I.PTP
50 ׀ 50 ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-51C / .I/.I.XT/.PTP/.I.PTP
43 ׀ 43 ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-53C / .I/.I.XT
20 ׀ 20 ׀ 20 ׀ x ׀ 20 ׀ x 1
VCXG-65C.R
x ׀ x ׀ x ׀ x ׀ 21 ׀ x 60
VCXG-82C / .I/.I.XT
x ׀ x ׀ x ׀ x ׀ x ׀ 1 4 - 22 μs 60
VCXG-91C
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-124C / .I/.I.XT/.PTP/.I.PTP
x ׀ 60 ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-125C.R
x ׀ x ׀ x ׀ 85 ׀ 85 ׀ x 60
VCXG-127C / .I/.I.XT
x ׀ x ׀ x ׀ x ׀ x ׀ 1 4 - 30 μs 60
VCXG-91C
x ׀ x ׀ 1 ׀ x ׀ 1 ׀ x 60
VCXG-201C.R / .I/.I.XT
x ׀ x ׀ x ׀ 115 ׀ 115 ׀ x 60
VCXG-204C
x ׀ x ׀ x ׀ x ׀ x ׀ 1 4 - 33 μs 60
VCXG-241C / .I/.I.XT
x ׀ x ׀ x ׀ x ׀ 39 ׀ 1 4 - 38 μs 60
Notice
VCXG-22M.R
VCXG-22C.R
In shutter mode Glob-
al Reset the expo-
sure time can only be
changed when the ac-
quisition is stopped.
In the shutter mode
Rolling Shutter
, the
acquisition does not
have to be stopped.
*)
.I/.I.XT only Release
2.1 , 3.0
**)
shutter mode Global
Reset
***)
shutter mode Rolling
Shutter
1)
range only relevant
with activated ShortEx-
posureTimeEnable
