7.11.4 BinningVertical
Number of vertical photo-sensitive cells to combine together. This increases the intensity
(or signal to noise ratio) of the pixels and reduces the vertical resolution (height) of the
image.
Name BinningVertical
Category ImageFormatControl
Interface IInteger
Access Read / Write
Unit -
Values see tables below (Increment: 1)
7.11.4.1 VCXG / .I / .I.XT / .PTP / .I.PTP
Notice
On the VCXG-15M binning is calculated in the sensor. In contrast to binning in the
FPGA, the binning in the sensor increases the frame rate.
Camera Type
BinningSelector
[Region0]
BinningSelector
[Sensor]
Monochrome
VCXG-02M 1 ... 2 1 ... 1
VCXG-04M 1 ... 2 1 ... 1
VCXG-13M / .I/.I.XT 1 ... 2 1 ... 1
VCXG-13NIR 1 ... 2 1 ... 1
VCXG-15M / .I/.I.XT 1 ... 2 1 ... 2*
VCXG-22M.R 1 ... 2 1 ... 1
VCXG-23M 1 ... 2 1 ... 1
VCXG-24M 1 ... 2 1 ... 1
VCXG-25M / .I/.I.XT 1 ... 2 1 ... 1
VCXG-32M / .I/.I.XT/.PTP/.I.PTP 1 ... 2 1 ... 1
VCXG-50MP 1 ... 2 1 ... 1
VCXG-51M /.XC / .I/.I.XT/.PTP/.I.PTP 1 ... 2 1 ... 1
VCXG-53M / .I/.I.XT 1 ... 2 1 ... 1
VCXG-53NIR
1 ... 2 1 ... 1
VCXG-65M.R 1 ... 2 1 ... 1
VCXG-82M / .I/.I.XT 1 ... 2 1 ... 2
VCXG-91M 1 ... 2 1 ... 1
VCXG-124M / .I/.I.XT/.PTP/.I.PTP 1 ... 2 1 ... 1
VCXG-125M.R 1 ... 2 1 ... 1
VCXG-127M / .I/.I.XT 1 ... 2 1 ... 2
VCXG-201M.R / .I/.I.XT 1 ... 2 1 ... 1
VCXG-204M 1 ... 2 1 ... 2
VCXG-241M / .I/.I.XT
1 ... 2 1 ... 2
*)
BinningHorizontal is also switched to 2
