Baumer VCXG Series - Digital-IO; LED Signaling

V4.7 | 06/24/2024 | 11165414
44
5.1.4 Digital-IO
Camera Customer Device
IO Power V
CC
OUT1
R
L
OUT1
IO GND
Pin 5
Pin 6
t
U
0
24V
t
ON
t
OFF
Camera Customer Device
IO Power V
CC
OUT1
Pin 5
R
L
OUT1
IO GND
Pin 6
U
t0
24V
t
ON
t
OFF
DigitalOutput:LowActive DigitalOutput:HighActive
CameraCustomer Device
DRV
Pin 3
Pin 4
IN1
GND IN1
Digital Input
5.1.5 LED Signaling
21
LED Signal Meaning
1
green static link active
green ash receiving
2
yellow static error
yellow ash transmitting
LED positions on Bau-
mer VCXG cameras.
