Baumer VCXG Series - Lens Mounting

V4.7 | 06/24/2024 | 11165414
36
VCXU
Camera Type
max. Temperature
(internal temperature sensor)
Monochrome / Color
VCXU-02M / VCXU-02C 75 °C (167 °F)
VCXU-04M / VCXU-04C 72 °C (161.6 °F)
VCXU-13M / VCXU-13C 75 °C (167 °F)
VCXU-15M / VCXU-15C 72 °C (161.6 °F)
VCXU-23M / VCXU-23C 72 °C (161.6 °F)
VCXU-22M.R / VCXU-22C.R 72 °C (161.6 °F)
VCXU-24M / VCXU-24C 72 °C (161.6 °F)
VCXU-25M / VCXU-25C 75 °C (167 °F)
VCXU-31M / VCXU-31C 72 °C (161.6 °F)
VCXU-32M / VCXU-32C 72 °C (161.6 °F)
VCXU-50M / VCXU-50C 72 °C (161.6 °F)
VCXU-51M / VCXU-51C 72 °C (161.6 °F)
VCXU-50MP 72 °C (161.6 °F)
VCXU-53M / VCXU-53C 75 °C (167 °F)
VCXU-65M.R / VCXU-65C.R 73 °C (163.4 °F)
VCXU-90M / VCXU-90C 72 °C (161.6 °F)
VCXU-91M / VCXU-91C 72 °C (161.6 °F)
VCXU-123M / VCXU-123C 72 °C (161.6 °F)
VCXU-124M / VCXU-124C 72 °C (161.6 °F)
VCXU-125M.R / VCXU-125C.R 75 °C (167 °F)
VCXU-201M.R / VCXU-201C.R 75 °C (167 °F)
4.3 Lens mounting
Notice
Avoid contamination of the sensor and the lens by dust and airborne particles when
mounting the lens to the device!
Therefore the following points are very important:
▪ Install the camera in an environment that is as dust free as possible!
▪ Keep the dust cover (bag) on camera as long as possible!
▪ Hold the camera downwards with unprotected sensor.
▪ Avoid contact with any optical surface of the camera!
