7.11.9.1 VCXG /.XC / .I / .I.XT / .PTP / .I.PTP
Camera Type Values
Monochrome
VCXG-02M 1
*
׀ 2 ... 480 (Increment: 1
*
׀ 2)
VCXG-04M 1
*
׀ 2 ... 540 (Increment: 1
*
׀ 2 )
VCXG-13M / .I/.I.XT 1
*
׀ 2 ... 1024 (Increment: 1
*
׀ 2)
VCXG-13NIR 1 ... 1024 (Increment: 1)
VCXG-14SWIR 2 ... 1032 (Increment: 2)
VCXG-15M / .I/.I.XT 1
*
׀ 4 ... 1080 (Increment: 1
*
׀ 4)
VCXG-22M.R 2 ... 1080 (Increment: 2)
VCXG-23M 1
*
׀ 2 ... 1200 (Increment: 1
*
׀ 2)
VCXG-24M 1
*
׀ 2 ... 1200 (Increment: 1
*
׀ 2)
VCXG-25M / .I/.I.XT 1
*
׀ 2 ... 1200 (Increment: 1
*
׀ 2)
VCXG-32M / .I/.I.XT/.PTP/.I.PTP 1
*
׀ 2 ... 1536 (Increment: 1
*
׀ 2)
VCXG-51M / XC .I/.I.XT/.PTP/.I.PTP 1
*
׀ 2 ... 2048 (Increment: 1
*
׀ 2)
VCXG-50MP 1
*
׀ 2 ... 2048 (Increment: 1
*
׀ 2)
VCXG-53M / .I/.I.XT 1
*
׀ 2 ... 2048 (Increment: 1
*
׀ 2)
VCXG-53NIR
1 ... 2048 (Increment: 1
*
׀ 2)
VCXG-65M.R 2 ... 2048 (Increment: 2)
VCXG-82M / .I/.I.XT 1 ... 2832 (Increment: 1)
VCXG-91M 1
*
׀ 2 ... 2160 (Increment: 1
*
׀ 2)
VCXG-124M / .I/.I.XT/.PTP/.I.PTP 1
*
׀ 2 ... 3000 (Increment: 1
*
׀ 2)
VCXG-125M.R 2 ... 3000 (Increment :2)
VCXG-127M / .I/.I.XT 1 ... 2992 (Increment: 1)
VCXG-201M.R / .I/.I.XT 2 ... 3648 (Increment: 2)
VCXG-204M 1 ... 4496 (Increment: 1)
VCXG-241M / .I/.I.XT 1 ... 4600 ׀ 4592
**)
(Increment: 1)
Color
VCXG-02C 2
*
׀ 4 ... 480 (Increment: 2
*
׀ 4)
VCXG-04C 2
*
׀ 4 ... 540 (Increment: 2
*
׀ 4)
VCXG-13C / .I/.I.XT 2
*
׀ 4 ... 1024 (Increment: 2
*
׀ 4)
VCXG-15C / .I/.I.XT 2
*
׀ 4 ... 1080 (Increment: 2
*
׀ 4)
VCXG-22C.R 4 ... 1080 (Increment: 4)
VCXG-23C 2
*
׀ 4 ... 1200 (Increment: 2
*
׀ 4)
VCXG-24C 2
*
׀ 4 ... 1200 (Increment: 2
*
׀ 4)
VCXG-25C / .I/.I.XT 2
*
׀ 4 ... 1200 (Increment: 2
*
׀ 4)
VCXG-32C / .I/.I.XT/.PTP/.I.PTP 2
*
׀ 4 ... 1536 (Increment: 2
*
׀ 4)
VCXG-51C / .I/.I.XT/.PTP/.I.PTP
2
*
׀ 4 ... 2048 (Increment: 2
*
׀ 4)
VCXG-53C / .I/.I.XT 2
*
׀ 4 ... 2048 (Increment: 2
*
׀ 4)
VCXG-65C.R 4 ... 2048 (Increment: 4)
VCXG-82C / .I/.I.XT 2 ... 4832 (Increment: 2)
VCXG-91C 2
*
׀ 4 ... 2160 (Increment: 2
*
׀ 4)
VCXG-124C / .I/.I.XT/.PTP/.I.PTP 2
*
׀ 4 ... 3000 (Increment: 2
*
׀ 4)
VCXG-125C.R 4 ... 3000 (Increment: 4)
VCXG-127C / .I/.I.XT 2 ... 2992 (Increment: 2)
VCXG-201C.R / .I/.I.XT 4 ... 3648 (Increment: 4)
VCXG-204C 2 ... 4496 (Increment: 2)
VCXG-241C / .I/.I.XT
2 ... 4592 (Increment: 2)
*)
≥ Release 3
**)
≥ Release 4
Notice
VCXU-201M.R (Rel. 4)
VCXG-201C.R (Rel. 4)
In pixel formats:
▪ Mono8
▪ Mono10
▪ Bayer RG8
▪ Bayer RG10
and Region of Interest
(ROI) (Height 1649 ...
3648) vertical partial
scan will be done in
the sensor.
This leads to an in-
crease of the frame
rate.
The other area (Height
1 ... 1648) is done
in the FPGA and the
frame rate does not
increase.
In the other pixel for-
mats, partial scan is
done only in the FPGA
and the frame rate
does not increase ei-
ther.
