7.1 Category: Action Control (GigE only)
Category that contains the Action control features.
7.1.1 ActionDeviceKey
Provides the device key that allows the device to check the validity of action commands.
The device internal assertion of an action signal is only authorized if the ActionDeviceKey
and the action device key value in the protocol message are equal.
Name ActionDeviceKey
Category ActionControl
Interface IInteger
Access Write only
Unit HexNumber
Values 0 - 4294967295 (Increment: 1)
7.1.2 ActionGroupKey
Provides the key that the device will use to validate the action on reception of the action
protocol message.
Name ActionGroupKey
Category ActionControl
Interface IInteger
Access Read / Write
Unit HexNumber
Values 0 - 4294967295 (Increment: 1)
7.1.3 ActionGroupMask
Provides the mask that the device will use to validate the action on reception of the action
protocol message.
Name ActionGroupMask
Category ActionControl
Interface IInteger
Access Read / Write
Unit HexNumber
Values 0 - 4294967295 (Increment: 1)
7.1.4 ActionSelector
Selects to which Action Signal further Action settings apply.
Name ActionSelector
Category ActionControl
Interface IInteger
Access Read / Write
Unit -
Values 1 - 1 (Increment: 1)
