Baumer VCXG Series - Boopticalblackpixelsconfigurationmode (SWIR Only)

V4.7 | 06/24/2024 | 11165414
178
Camera Type Values
Color
VCXU-02C
640
VCXU-04C 720
VCXU-13C
1280
VCXU-15C
1440
VCXU-22C.R 1920
VCXU-23C 1920
VCXU-24C 1920
VCXU-25C 1920
VCXU-31C 2048
VCXU-32C 2048
VCXU-50C
2448
VCXU-51C 2448
VCXU-53C 2592
VCXU-65C.R 3072
VCXU-90C 4096
VCXU-91C 4096
VCXU-123C 4096
VCXU-124C 4096
VCXU-125C.R 4000
VCXU-201C.R 5472
7.11.26 boOpticalBlackPixelsCongurationMode(SWIRonly)
Controls if the optical black pixels conguration mode is active. Enables extended sensor
width to display the optical black pixels in every line.
Notice
The camera must be stopped before this feature can be edited.
Instruction
1. Open the camera in Camera Explorer.
2. Stop the Image acquisition.
3. Set the boOpticalBlackPixelsCongurationMode to On.
-> WidthMax is increased to 1392
4. Adjust the value for Width.
5. Start the Image acquisition.
-> The set number of black pixels is displayed on the right side of each image line.
Name boOpticalBlackPixelsCongurationMode
Category ImageFormatControl
Interface IEnumeration
Access Read / Write
Unit -
Values
On
Enables black pixels conguration mode.
O󰀨 Disables black pixels conguration mode.
