Baumer VCXG Series - Blacklevelselector; Gain

V4.7 | 06/24/2024 | 11165414
81
VCXU-124M / VCXU-124C 0 ... 255 DN12
VCXU-125M.R / VCXU-125C.R 0 ... 255 DN12
VCXU-201M.R / VCXU-201C.R 0 ... 255 DN12
7.2.3 BlackLevelSelector
Selects which Black Level is controlled by the various Black Level features.
Name BlackLevelSelector
Category AnalogControl
Interface IEnumeration
Access Read / Write
Unit -
Values All Black Level will be applied to all channels or taps.
7.2.4 Gain
Motion blur is unacceptable in high quality image acquisition. Exposure times are there-
fore limited. However, this results in low output signals from the camera and dark images.
To solve this issue, the signals can be amplied by a user-dened gain factor within the
camera.
Notice
Increasing the gain factor also increases image noise.
Controls the selected gain as an absolute physical value.
Name Gain
Category AnalogControl
Interface IIFloat
Access Read / Write
Unit -
Values see tables below
