Baumer VCXG Series - Sensorwidth; Testpattern

V4.7 | 06/24/2024 | 11165414
172
7.11.21 SensorWidth
E󰀨ective width of the sensor in pixels.
Name SensorWidth
Category ImageFormatControl
Interface IInteger
Access Read only
Unit -
Values 0 ... 65535 (Increment: 1)
7.11.22 TestPattern
Selects the type of test pattern that is generated by the device as image source.
Name TestPattern
Category ImageFormatControl
Interface IEnumeration
Access Read / Write
Unit -
Values see table below
GreyDiagonalRamp Image is lled diagonally with an image that goes from the
darkest possible value to the brightest.
GreyDiagonalRampHori-
zontalAndVerticalLineMov-
ing
Image is lled diagonally with an image that goes from
the darkest possible value to the brightest with moving
horizontal and vertical lines.
GreyDiagonalRampHori-
zontalLineMoving
Image is lled diagonally with an image that goes from
the darkest possible value to the brightest with moving
horizontal lines.
GreyDiagonalRampVerti-
calLineMoving
Image is lled diagonally with an image that goes from
the darkest possible value to the brightest with moving
vertical lines.
GreyHorizontalRamp
Image is lled horizontally with an image that goes from
the darkest possible value to the brightest.
GreyHorizontalRampHori-
zontalAndVerticalLineMov-
ing
Image is lled horizontally with an image that goes from
the darkest possible value to the brightest with moving
horizontal and vertical lines.
GreyHorizontalRampHori-
zontalLineMoving
Image is lled horizontally with an image that goes from
the darkest possible value to the brightest with moving
horizontal lines.
GreyHorizontalRampVerti-
calLineMoving
Image is lled horizontally with an image that goes from
the darkest possible value to the brightest with moving
vertical lines.
GreyVerticalRamp
Image is lled vertically with an image that goes from the
darkest possible value to the brightest.
GreyVerticalRampHorizon-
talAndVerticalLineMoving
Image is lled vertically with an image that goes from the
darkest possible value to the brightest with moving hori-
zontal and vertical lines.
