7.2 Category: AnalogControl
Features in this chapter describes how to inuence the analog features of an image, such
as gain, black level, brightness correction and gamma.
7.2.1 BalanceWhiteAuto (color cameras only)
Controls the mode for automatic white balancing between the color channels. The white
balancing ratios are automatically adjusted.
Name BalanceWhiteAuto
Category AnalogControl
Interface IEnumeration
Access Read / Write
Unit -
Values
Continuous White balancing is constantly adjusted by the device.
O󰀨
White balancing is o󰀨.
Once
White balancing is automatically adjusted once by the de-
vice. Once it has converged, it automatically returns to the
O󰀨 state.
The levelling can take several images.
Notice
When images are acquired in trigger mode, the white bal-
ance a󰀨ects on the next acquired image.
7.2.2 BlackLevel
Controls the analog black level as an absolute physical value. This represents a DC o󰀨set
applied to the video signal.
Name BlackLevel
Category AnalogControl
Interface IFloat
Access Read / Write
Unit -
Values see tables below (Increment: 1.00)
