7.16.4.1 PtpClockAccuracy
Indicates the expected accuracy of the device PTP clock when it is the grandmaster, or in
the event it becomes the grandmaster.
Name PtpClockAccuracy
Category
TansportLayerControl → PtpControl
Interface IEnumeration
Access Read only
Unit -
Values
Within1us
Within2p5u
7.16.4.2 PtpClockID
Returns the latched clock ID of the PTP device. PTP Parent Clock ID.
Notice
Byte 0 of the IEEE ClockIdentity eld is mapped to the MSB.
Name PtpClockID
Category
TansportLayerControl → PtpControl
Interface IInteger
Access Read only
Unit MacAdress
Values 80-00-00-00-00-00 ... 7F-FF-FF-FF-FF-FF-FF-FF (Increment: 1)
7.16.4.3 PtpDataSetLatch
Latches the current values from the device’s PTP clock data set.
Name PtpDataSetLatch
Category
TansportLayerControl → PtpControl
Interface ICommand
Access Write only
Unit -
Values -
