7.6.3 CounterEventSource
Select the events that will be the source to increment the Counter.
Name CounterEventSource
Category CounterAndTimerControl
Interface IEumeration
Access Read / Write
Unit -
Values
Counter1End Counts the number of Counter1 End.
Counter2End Counts the number of Counter2 End.
ExposureActive Counts all Exposures.
FrameTransferSkipped Counts when a frame transfer skipped.
Line0 Counts the number of signals on I/O Line0.
Line1
*
Counts the number of signals on I/O Line1.
Line2
*
Counts the number of signals on I/O Line2.
Line3
* / **
Counts the number of signals on I/O Line3.
FrameTrigger Counts the number of Frame Start Trigger.
Off Disable the Counter Reset trigger.
TriggerSkipped Counts when a Trigger skipped.
*)
≥ Release 3
**)
only VCXG.I / .XT /.PTP
7.6.4 CounterReset
Does a software reset of the selected Counter and starts it. The counter starts counting
events immediately after the reset unless a Counter trigger is active. CounterReset can
be used to reset the Counter independently from the CounterResetSource. To disable the
counter temporarily, set CounterEventSource to O󰀨.
Notice
Note that the value of the Counter at time of reset is automatically latched and reected
in the CounterValueAtReset.
Name CounterReset
Category CounterAndTimerControl
Interface ICommand
Access Write only
Unit -
Values -
