Baumer VCXG Series - LED Signaling

To Next Page

To Previous Page

V4.7 | 06/24/2024 | 11165414

5.2.4 LED Signaling

LED Signal Meaning

yellow static error

yellow ash transmitting

green static link active

green ash receiving

LED positions on Bau-

mer VCXG.I / .XT cam-

eras.
