Patient monitor User’s manual
9
Protection against the
effects of defibrillation
and blocking after
defibrillation
<5s after Defibrillation. (Mon or Surg mode)
Recovery time of
equipment from
electrodes polarization
after defibrillation
ECG waveform will recover to the baseline in 10 s.
Pacer pulse mark
With pacer pulse detector, complies with IEC 60601-2-27:
2005, 50.102.12. For the pacer pulse in compliance with
following conditions, pacer mark will be signed on the
screen(≥ 2 mm):
Pacing pulse amplitudes: ±2 mV to ±700mV
Pacing pulse widths: 0.1 ms to 2ms
Rise time: 10 us to 100us
HR
Measurement range
Adult: 10 bpm to 300 bpm
Pediatric and Neonatal: 10 bpm to 350 bpm
Resolution
1 bpm
Accuracy
±1% or ±1 bpm, whichever is greater
Detecting sensitivity
(II lead)
≥0.20mVpp
Response time of HR
meter to change in HR
<12s
Response of HR to
QRS amplitude is
1mVp-p, width is
10ms
Adult: without response
Alarm range
0 bpm to 300 bpm, high/low limit can be adjusted
continuously.
ST
segment
Measurement Calculating I, II, V- lead etc. at the same time
