131
A I. TECHNICAL SPECIFICATIONS
PLEASE NOTE
The manufacturer accepts no liability for damage caused by incorrect use of the apparatus.
GENERAL SPECIFICATIONS
Automatic random and continual access analyzer aimed at giving results per patient, with direct photometric reading over
a reactions rotor.
Preparation cycle time 15 s (up to 240 prep/h)
Warm-up time 25 min
Reading time for each preparation Every 15 s, up to 15 min
Dimensions 1080 x 695 x 510 mm (42.5"x27.4"x20.1")
(length x depth x height)
Weight 73 kg (162 lb)
REAGENTS AND SAMPLES TRAY
Positions for racks 6
Detection of up to 15 different types of racks
Capacity of the sample racks 24
Maximum number of samples 120
ø13 mm, ø15 mm sample tubes (max. height 100 mm), ø13 mm paediatric well
Capacity of the reagent racks 10
Maximum number of reagents 50 (plus 3 auxiliary fixed positions)
20 ml and 50 ml reagent bottles
Possible configurations
Sample racks Reagent racks Number of samples Number of reagents
1 5 24 50
2 4 48 40
3 3 72 30
4 2 96 20
5 1 120 10
DISPENSING SYSTEM
NEEDLE
Detachable tip
Vertical length 110 mm
Capacity level detection
Self-adjustment of position
NEEDLE THERMOSTATATION SYSTEM
Actuator 1 Peltier cell
Control Fuzzy Logic
Thermostatation time < 6 s
Dispensation temperature 37°C
Trueness ± 0.5°C
Repeatability ± 0.5°C
