Service manual
44
TP36V - 36V voltage
TPGND - GND
TP1 - 5V digitals
TP2 - Lamp voltage from 11.7 V <12V
TP3 - 12V Analogicals
TP4 - 12V Valves and diaphragm pumps
TP5 - 12V thermostatation
The existing bridge is to enable the different supply voltages. It has the same function as the enable of the J1 connector.
List of LED diodes:
D3 - Indicates 5V activated
D4 - Indicates 12V lamp activated
D7 - Indicates 12V valves activated
D8 - Indicates 12V analogicals activated
D10 - Indicates 12V thermos activated
3.2 Power Supply Board (CIIM00007)
This is made up of 5 different switched voltage regulators that enable distribution of the power supply in accord with the
requirement of each subsystem.
Connector Function Pins
J1 5 V output and enabling of
power supply board
1 - 5V
2 - GND
3 - ENABLE
J2 Output voltage 12 V for lamp
supply
1 - 12 V
2 - GND
J3 36 V input from the SP300-36
power supply board
1 - 36V
2 - NC
3 - GND
J4 36V and 12 V output voltage.
Supplies voltage for motors,
electrovalves and membrane
pumps and thermostatisation
systems.
1 - 36V
2 - GND
3 - 12V Valves
4 - GND
5 - 12 V thermostatisation
6 - GND
7 - 12 V analogic
8 - GND
J5,J6 Fan connection on the central
back cover.
1 - 12V
2- GND
