34
Service manual
1
3
2
1
4
3
2
5
6
The metallic support (1) supports the connector (2) for the network cable, the instrument switch (3) and the fuse
holder (4).
2.2.4.3. Electronics cover
(1) BACK COVER OF THE ELECTRONICS
(2) FAN GRILLS
(3) FANS
