biosystems A25 User Manual

135
Main voltage measurement points
CIIM00007 Power supply board
TP1- 5V [4.9-5.1] V
TP2 - 12V [11.7 -11.9] V
TP3 - 12V [11.8-12.2] V
TP4 - 12V [11.8-12.2] V
TP5 - 12V [11.8-12.2] V
TP36 [32-40] V
CIIM0006 Microprocessor board
TP50 - Vref Z motor [3-4] mV
TP51 - Vref Ymotor [3-4] mV
TP52 - Vref Xmotor [3-4] mV
TP53 - Vref pump motor [3-4] mV
TP54 - Vref filter wheel motor [3-4] mV
TP55 - Vref rotormotor [3-4] mV
Main adjustment values of the analyzer
Tolerances
Operating arm positioning
X axis loss of steps
Loss of steps [-3,3]
Y axis loss of steps
Loss of steps [-3,3]
Z axis loss of steps
Loss of steps [-3,3]
Loss of steps rotor motor
Loss of steps [-3,3]
Loss of steps filter drum motor
Loss of steps [-3,3]
Loss of steps pump motor
Loss of steps [-4,4]
XY position adjustment
X origin [11,51]
Y origin [2,48]
X racks tray [1337,1379]
Y racks tray [311,359]
X washing station [1337,1379]
Y washing station [-5,45]
X rotor [2870,2910]
Y rotor [660,701]
Self-centering of needle
X Offset [-3,3]
Y Offset [-3,3]
Level control scales
Water 0 L (0 D) [-3%,3%]
Water 1.35 L (1 D) [35%,65%]
Water 2.7 L (2 D) [95%,105%]
Waste 0 L (0 D) [-3%,3%]
Waste 1.35 L (1 D) [35%,65%]
Waste 2.7 L (2 D) [95%,105%]
A II. ADJUSTMENT MARGINS TABLES
Level detection sensitivity
Rack 2 [45,100]
Rack 5 [45,100]
Calculated (Adjusted) [45,100]
Positioning of the dispensing point
Dispensing rotor [-10,30]
Fine rotor X [2870,2910]
Filter wheel positioning
Positioning [-6,0]
Positioning of rotor in optic
Positioning [-12,6]
Needle thermostatation
Set point temperature [35.5,38.5]
Rotor thermostatation
Set point temperature [36,38]
Integration times
F1 340 nm [45,70]
F2 405 nm [8,26]
F3 505 nm [8,26]
F4 535 nm [8,26]
F5 560 nm [8,26]
F6 600 nm [8,26]
F7 635 nm [8,26]
F8 670 nm [11,29]
Number of counts
F1 340 nm [750000,970000]
F2 405 nm [840000,970000]
F3 505 nm [840000,970000]
F8 670 nm [840000,970000]
Darkness counts
F1 340 nm [3700,4300]
F2 405 nm [3700,4300]
F3 505 nm [3700,4300]
F8 670 nm [3700,4300]
SMF repeatability (Noise)
Dev. Est. NC. F0 Covered  55
Dev. Est. Abs. F1 340 nm  0.0004
Dev. Est. Abs. F2 405 nm  0.0006
Dev. Est. Abs. F3 505 nm  0.0004
Dev. Est. Abs. F8 670 nm  0.0007
Stability at 505 nm
Dev. Est. Abs. F3 505 nm  0.0008
Max. NC [840000,970000]
Min. NC [840000,970000]
Max NC / Min NC  1.006
Repeatability MF (Repeatability)
Dev. Est. Abs. F1 340 nm  0.0008
Dev. Est. Abs. F2 405 nm  0.0006
Dev. Est. Abs. F3 505 nm  0.0005
Dev. Est. Abs. F4 535 nm  0.0005
Dev. Est. Abs. F5 560 nm  0.0005
Dev. Est. Abs. F6 600 nm  0.0005
Dev. Est. Abs. F7 635 nm  0.0005
Dev. Est. Abs. F8 670 nm  0.0005
