biosystems A25 - Thermostated Rotor and Photometric System

28
Service manual
2.2.3.1. Thermostated rotor and photometric system
(1) METHACRYLATE ROTOR
(2) HEATING CHANNEL
(3) THERMAL INSULATION OF THE HEATING CHANNEL
(4) PELTIER CELLS
(5) RADIATORS
(6) THERMAL INSULATION BUSHES
(7) ROTOR FASTENING SCREW
(8) ROTOR CENTERER
(9) THERMAL INSULATION OF THE GEAR SUPPORT
(10) GEAR SUPPORT
(11) START PHOTODETECTOR
(12) ROTOR SHAFT
(13) BEARINGS
(14) ROTOR PULLEY
(15) GEARED BELT
(16) MOTOR SUPPORT
(17) MOTOR SPACER
(18) MOTOR
(19) MOTOR PULLEY
(20) PHOTOMETRIC SYSTEM SUPPORT COVER
(21) LEAKPROOF SEAL
(22) LOWER PHOTOMETRIC SYSTEM SUPPORT COVER
(23) PHOTODIODE GRILL CENTERER
(24) PHOTOMETRIC SYSTEM BOARD
(25) PHOTODIODE SPACER
(26) ROTOR GRILL
(27) TEMPERATURE PROBE
(28) THERMAL INSULATION OF PROBE
(29) COVER DETECTOR
(30) EARTH CONNECTION
(31) DRAINAGE TUBES
(32) COLUMNS
18
17
16
8 1
7
2
5
3
