biosystems A25 User Manual

Service manual
54
- Detecting Y side: OK. The correction is Y=Ycal+-1
Auto-Adjustment of the probe is done
Peltier Cells and Drivers Test
- Probe Peltier Driver Test: Ok!
- Rotor Peltiers Driver Test: Ok!
Hardware Initializated
HC
Detecting the reactions rotor
- Filter 340nm Found! (1)
- The lamp doesn't need time for stabilization
- Rotor detected! (Average= 749967 Desvest=150577.36)
Send Status
Rx s=0
Rx service task
N=1 T=0 F=156 P1=0 P2=0 P3=0
End Service Recipe
Send service
Rx s=1
Rx service task
N=1 T=0 F=157 P1=0 P2=0 P3=0
End Service Recipe
Send service
Rx s=0
Rx service task
N=1 T=0 F=152 P1=0 P2=0 P3=0
End Service Recipe
E=>0
Send service
There are a few keys that work with the Hyperterminal, to press some keys the analyser give information about some
element, the following keys has the function:
H: Help, help, shows the help text
R: Rotor Temperature, shows the rotor temperature
P: Probe Temperature, shows the needle temperatare
S: Level Scales, shows the scales mesures in %
A: Last A25 Stress Results
L: Actual Sensibility of Level Detection
N: Activate additional information of level detection (only internal use)
K: Deactivate the power supply
B: Activate the buzzer
b: Deactivate the buzzer
E: Generate an encoder error (only internal use)
I: Activate the encoder interrupt (only internal use)
1: Increase the filter wheel position
2: Decrease the filter wheel position
9: Mesure the whole rotor, step by step
G: Once finish a work list, push the G and send to the hyperteminal more detailed
information of the work list managemnet
D: Show the mesure depending on the number of key pressed
1st press: activate the internal test DDC112, always show the same count number
2nd press: activate the normal mesure DDC112, show the count number mesured
3th press: stop the DDC112 mesure
+: Increase the integration time in 0.5ms
-: Decrease the intergration tie in 0.5ms
3.9 Boards interconnection
The following schematics shows the connection between boards and the differents elements has the analyser.
