CODE DESCRIPTION (Sort by code)
AC10116 Tool set slot key-1
AC10117 Tool set lens key-1
AC10118 knurled screw DIN653 M4x25
VA10355 CN-202 mains connector
ZO10407 Fuse holder
ME10490 Fan grill
PC10752 Varistor board
AC11511 Full operating arm
ME11512 X carriage belt
ME11513 Y carriage belt
ME11514 Z carriage belt
MO11516 Y motor
MO11518 X motor
AC11519 Encoder-spring unit, with motor
AC11520 Thermostated needle set
AC11521 Thermistor
MO11522 60 mm fan
AC11525 Thermostated probe upper fitting
ME11526 Full dispensing pump
AC11527 Dispensing pump seals
AC11528 Dispensing pump fluidic chamber
ME11530 3-way electrovalve
TU11531 Operating arm Teflon tube
TU11532 Dispensing pump Teflon tube
TU11533 Container tube unit
AC11534 Washing system diaphragm pump
ME11535 2-channel electrovalve with nuts
AC11536 Washing system restrictor
TU11537 Washing system PVC tubes
AC11538 Washing station cover
AC11539 Waste container nut and cap
CE11540 Load cell
AC11542 Rotor temperature probe, with thermal
insulation
ME11543 Rotor belt
MO11544 Rotor motor
AC11545 Full reactions rotor
AC11545 Rotor cover detector
AC11546 Filter wheel body
MO11547 Filter wheel motor
AC11548 Leakproof joint of the photometric system
ME11549 Hydro-pneumatic cylinder of the cover hinge
AC11550 Arm housing
PC11551 Microprocessor board
PC11552 Photometric system board
PC11553 Needle conditioning board
PC11554 Racks detection board
PC11555 Front indicator board
PC11556 Power supply board
IN11557 Main switch
MO11558 80 mm fan
AC11559 Cover window
ZO11560 Lamp holder
CE11561 Peltier cell
FO11562 Start photodetector (without cable)(5)
List of spares exclusive to the technical support service.
TU11569 A25 tube set
FO11570 5 Photodetector set
AC11571 Racks support tray
CA11572 Base housing 1
CA11573 Base housing 2
AC11574 Full hinges
AC11575 Auxiliary cover
AC11579 Base
CA11580 Upper housing
VA11581 Upper housing transparent plastic
AC11582 Metal base of the needle detection base
AC11740 X track rail with two slide units
AC11741 Y track rail with slide unit
AC11742 Z track rail with slide unit
AC11743 Linear slide unit
AC11744 Service manual in Spanish
AC11745 Service manual in English
AC11749 Liquid system contained cap
AC11859 Fastening bolt YZ-1 axes
AC11860 Temperature adjustment tool
PC11862 Communication board
AC11892 CD service program
AC11930 Ceramic ‘piston set with motor
