The front housing (1) is screwed to the base and can be removed very easily without the need for removing any other
analyzer component. The rear housing (2) is also screwed to the base. The main cover (3) is screwed to the hinges. The
methacrylate (4) makes it possible to observe the functioning of the analyzer with the cover closed. The housing (5)
covers the Y carriage and the Z carriage of the analyzer. The cover (6) gives access to the optical system, making it
possible to change the lamp and filters with ease. The cover (7) covers the reactions rotor and readings.
