Service manual
40
Connector Function Pins
J19 Weighting system for waste and system liquid bottles 1 - Vdc
2 - GND
3 - V+
4 - V-
5 - Vdc
6 - GND
7 - V+
8 - V-
J24 Rotor connector
1 - Vdc
2 - Rotor cover
3 - Home rotor
4 - GND
5 - Vdc home rotor
6 - Filter wheel home
7 - GND
8 - Vdc Filter wheel home
9 - Rotor thermostatation
10 - GND
11 - Analogic 12 V
12 - GND
J25 Communications Board Connection (CIIM00019)
1 - Vdc
2 - GND
3 - Tx0
4 - GND
5 - Rx0
6 - GND
7 - GND
8 - Tx1
9 - GND
10 - Rx1
J27 Needle Peltier
1 - peltier, red
2 - peltier, black
J28 Rotor Peltier
1 - peltier, red
2 - peltier, black
J29 Needle Board Interconnection (CIIM00008)
1 - GND
2 - Home Z
3 - Needle thermistor
4 - Needle level detector
5 - GND
6 - 12 V
