List Mode 37
– The interaction with the list will vary depending on the chosen Pace. See 5.1
5. Select List Abort to end the list before all steps elapse. If the all steps elapse the list will end and the output will be
set to chosen After List parameter.
– If After List is set to DC the output will output the Vset and Iset values.
– If After List is set to Last the output will output the values of the last step in the list.
Note:
While the list is running the user can adjust the current step output by setting Vset or Iset on the main display. Doing so
will immediately change the value of the ongoing output. However, the set value will not be saved to the list. Once the
dwell time of the step has elapsed the list will continue and output the next step.
If Trigger source is set to manual,Vset/Iset will be available in the F3 softkey as shown in gure 5.9. The rotary knob
and numeric keypad can be used to adjust the selected value.Vset/Iset will be available as shown in gure 5.9.
Figure 5.9 Single Channel Display Vset/Iset
