Specications 79
Model 9240 9241 9242
Output Rating
Voltage 32 V 60 V
Current 8 A 4 A 10 A
Maximum Output 120 W 200 W
Load Regulation
(1)
± (% output + oset)
Voltage ≤0.01% + 3 mV
Current ≤0.1% + 3 mA
Line Regulation ± (% output + oset)
Voltage ≤0.01% + 3 mV
Current ≤0.1% + 3 mA
Ripple and Noise ( 20 Hz to 20 MHz )
Normal Mode Voltage p-p ≤5 mV ≤10 mV
Normal Mode Voltage rms ≤1 mV ≤2 mV
Normal Mode Current rms ≤3 mA
Programming / Readback Resolution
Voltage 1 mV
Current 1 mA
Programming / Readback Accuracy ± (% output + oset)
Voltage 0.03% + 4 mV 0.03% + 8 mV
Current 0.1% + 5 mA 0.1% + 3 mA
Temperature Coecient per °C
Voltage 6.4 mV / °C 12 mV / °C
Current 1.6 mA / °C 0.8 mA / °C
Output Response Time
(2)
Rise Time
Full load 10 ms 20 ms
No load 10 ms 20 ms
Fall Time
Full load 10 ms 20 ms
No load 250 ms 250 ms
Transient Response
(3)
Time 0.5 ms
Protection
OVP
Range 35.2 V 66 V
Accuracy 320 mV 600 mV
OCP
Range 8.8 A 4.4 A 11 A
Accuracy 80 mA 40 mA 100 mA
