Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
Torque limitation in generator mode, as a % or in 0.1% increments of the rated torque in
[Torque increment]
(IntP) parameter, page 216.
See page 216.
tr
H
*
[Traverse freq. high]
0 to 10 Hz 4 Hz
Traverse high. See page 242.
trL
*
[Traverse freq. low]
0 to 10 Hz 4 Hz
Traverse low . See page 242.
qSH
*
[Quick step High]
0 to
[Trave rse fre q. high]
(trH)
0 Hz
Quick step high. See page 242.
qSL
*
[Quick step Low]
0
to
[Trave rs e
freq.
low]
(
trL
0 Hz
Quick step low . See page 242.
Ctd
[Current threshold]
0 to 1.5 In (1) In (1)
Current threshold for
[I attaine d]
(CtA)
function assigned to a relay or a logic output (see page 138). See page 252.
tt
H
[High torque thd.]
-300% to +300% 100%
High
torque
threshold
for
[High
tq.
att.]
(
tt
HA
)
function
assigned
to
a
relay
or
a
logic
output
(see
page
138),
as
a
%
of
the
rated motor torque. See page 253.
tt
L
[Low torque thd.]
-300% to +300% 50%
Low torque threshold for
[Low tq. att.]
(ttLA)
function assigned to a relay or a logic output (see page 138), as a % of the rated
motor torque. See page 253.
FqL
*
[Pulse warning thd.]
0 Hz to 20,000 kHz 0 Hz
Speed threshold measured by the
[FREQUENCY METER]
(FqF-)
function, page 266, assigned to a relay or a logic output
(see page 138). See page 253.
Ftd
[Freq. threshold]
0.0 to 599 Hz HSP
Motor frequency threshold for
[Freq.Th.att.]
(FtA)
function assigned to a relay or a logic output (see page 138), or used by the
[PAR A M.
SET
SWITC H IN G ]
(
MLP
-
)
function,
page
230.
See
page
253.
F2d
[Freq. threshold 2]
0.0 to 599 Hz HSP
Motor frequency threshold for
[Freq. th.2 attained]
(F2A)
function assigned to a relay or a logic output (see page 138), or used
by the
[PARAM . SET SWITCHING]
(MLP-)
function, page 230. See page 253.
FF
t
*
[Freewheel stop Thd]
0.2 to 599 Hz 0.2 Hz
Speed threshold below which the motor w ill sw itch to freewheel stop.
This parameter supports switching from a ramp stop or a fast stop to a freewheel stop below a low speed threshold.
It
can
be
accessed
if
[Type
of
stop]
(
Stt
)
is
set
to
[Fast
stop]
(
FSt
)
or
[Ra mp
stop]
(
rM
P
)
and
if
[Brak e
assignm e nt ]
(bLC) and
[Auto DC inje ction]
(AdC) are not configured. See page 173.
tt
d
[Motor therm. level]
0 to 118% 100%
Threshold for motor thermal alarm (logic output or relay). See page 255.
JPF
[Skip Frequency]
0 to 599 Hz 0 Hz
Skip frequency. This parameter helps to prevent prolonged operation within an adjustable range around the regulated frequency.
This function can be used to help to prevent a speed, w hich would cause resonance, being reached. Setting the function to 0
renders it inactive. See page 183.
JF2
[Skip Frequency 2]
0 to 599 Hz 0 Hz
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > SET-
