Configuration Mode (ConF)
103
Code Nam e / De s cription Adjustment range Factory setting

2nd skip frequency. This parameter helps to prevent prolonged operation w ithin an adjustable range around the regulated
frequency. This function can be used to help to prevent a speed, w hich would cause resonance, being reached. Setting the
function to 0 renders it inactive. See page 183.
JF3

[3rd Skip Frequency]
0 to 599 Hz 0 Hz
3rd skip frequency. This parameter helps to prevent prolonged operation w ithin an adjustable range around the regulated
frequency. This function can be used to help to prevent a speed, w hich would cause resonance, being reached. Setting the
function to 0 renders it inactive. See page 183.
JFH
*

[Skip.Freq.Hysteresis]
0.1 to 10 Hz 1 Hz
Parameter visible if at least one skip frequency
[Sk ip Freque ncy]
(JPF),
[Sk ip Freque ncy 2]
(JF2) or
[3rd Sk ip Freque ncy]
(JF3) is different from 0.
Skip frequency range: betw een
(JPF
JFH)
and
(JPF
+
JFH)
for example.
This adjustment is common to the 3 frequencies
(JPF, JF2, JF3).
See page 183.
LUn
*

[Unld.Thr.Nom.Speed]
20 to 100% of
[Rated m ot. curre nt]
(nCr)
60%
Underload threshold at rated motor frequency (
[Rated m otor freq.]
(FrS)
page 86), as a % of the rated motor torque.
Visible only if
[Unld T. Del. De te ct]
(ULt)
page 270 is not set to 0.
See page 270.
LUL
*

[Unld.Thr.0.Speed]
0 to
[Unld.Thr.Nom .Spe e d]
(LUn)
0%
Underload threshold at zero frequency, as a % of the rated motor torque.
Visible only if
[Unld T. Del. De te ct]
(ULt)
page 270 is not set to 0.
See page 270.
rMUd
*

[Unld. Freq.Thr. Det.]
0 to 599 Hz 0 Hz
Underload detection minimum frequency threshold. See page 270.
Srb
*

[Hysteresis Freq.Att.]
0.3 to 599 Hz 0.3 Hz
Maximum deviation betw een the frequency reference and the motor frequency, which defines steady state operation.
See page 270.
FtU
*

[Underload T.B.Rest.]
0 to 6 min 0 min
Minimum time permitted betw een an underload being detected and any automatic restart.
In
order
for
an
automatic
restart
to
be
possible,
the
value
of
[Max.
restart
time ]
(
tAr
)
page
252
must
exceed
that
of
this
parameter by at least one minute. See page 271.
LOC
*

[Ovld Detection Thr.]
70% to 150% of
[Rated m ot. curre nt]
(nCr)
110%
Overload detection threshold, as a % of the rated motor current
[Rated m ot. current]
(nCr). This value must be less than the
limit current in order for the function to w ork. See page 272.
Visible only if
[Ovld Tim e De tect.]
(tOL)
is not set to 0.
This parameter is used to detect an "application overload". This is not a motor or drive thermal overload.
FtO
*

[Overload T.B.Rest.]
0 to 6 min 0 min
Minimum time permitted betw een an overload being detected and any automatic restart.
In
order
for
an
automatic
restart
to
be
possible,
the
value
of
[Max.
restart
time ]
(
tAr
)
page
252
must
exceed
that
of
this
parameter by at least one minute. See page 272.
LbC
*

[Load correction]
0 to 599 Hz 0 Hz
Rated correction in Hz. See
[Load correction]
(LbC) page 122.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > SET-
