Configuration Mode (ConF)
Code Nam e / De s cription Adjustment range Factory setting
FFM
Std
rUn
StP
[Fan Mode]
[Standard]
(Std)
If
[Fan Mode]
(FFM) is set to
[Never]
(Stp),
the fan of the drive is disabled.
Service life of electronic com ponent is reduced.
NOTICE
DAMAGE TO THE DRIVE
The am bient tem perature m ust be lim ited to 40°C (104°F)
Failure to follow these instructions can result in equipment damage.
[Standard]
(Std):
The fan starts and stops automatically according to the drive thermal state
[Alw ays ]
(rUn): The fan is started
[Neve r]
(Stp):
The fan is stopped
SdS
[Scale factor display]
0.1 to 200 30
Used
to
display
a
value
in
proportion
to
the
output
frequency
[Output
frequenc y]
(
rFr
):
the
machine
speed,
the
motor
speed,
etc.
The display w ill show
[Cust.
output
value]
(
SP
d3
)
=
[Scale
factor
display]
(
Sd
S
)
x
[Output
frequenc y]
(
rF
r
)
to
2
decimal
places
1000
•
If [Scale factor display] (SdS)
y
1, [Cust. output value] (SPd1) is displayed (possible definition = 0.01)
•
If 1 < [Scale factor display] (SdS)
y
10, [Cust. output value] (SPd2) is displayed (possible definition = 0.1)
•
If [Scale factor display] (SdS) > 10, [Cust. output value] (SPd3) is displayed (possible definition = 1)
•
If
[Scale
factor
display]
(
SdS
)
>
10
and
[Scale
factor
display]
(
SdS
)
x
[Output
frequency]
(
rFr
)
>
9,999:
example: for 24,223, display w ill show 24.22
-
If
[Scale
factor
display]
(
Sd
S
)
>
10
and
[Scale
factor
display]
(
SdS
)
x
[Output
frequency]
(
rFr
)
>
65,535,
display
locked at 65.54
Example: Display motor speed for
4-pole motor, 1,500 rpm at 50 Hz (synchronous speed):
[Scale factor display] (SdS) = 30
[Cust.
output
value]
(
SPd3
)
=
1,500
at
[Output
frequenc y]
(
rF
r
)
=
50
Hz
(1)
In corresponds to the rated drive current indicated in the Installation manual or on the drive nameplate.
(2)
If a graphic display terminal is not in use, values greater than 9,999 w ill be displayed on the 4-digit display w ith a period
mark after the thousand digit, example: 15.65 for 15,650.
These parameters only appear if the corresponding function has been selected in another menu. When the parameters can
also be accessed and adjusted from w ithin the configuration menu for the corresponding function, their description is detailed
in these menus, on the pages indicated, to aid programming.
Parameter that can be modified during operation or w hen stopped.
To change the assignment of this parameter, press the ENT key for 2 s.
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > DRC-
2 s
*
