Configuration Mode (ConF)
132
[Min
value]
(-100%)
-
[Interm. point X]
For range 0  100%
Referenc e
100%
[Interm. point Y]
0%
[Min value]
(0%)
[Interm. point X] [Max value]
(100%)
20 mA or
10 V
Current or
voltage
input
Note: For [Interm . point X], 0% corresponds to [Min value] and 100% to [Max value].
For range -100%  100%
Reference
100%
[Interm. point Y]
0%
- [Interm. point Y]
- 100%
0% [Interm. point
X]
[Max value]
(100%)
Current or
voltage input
20 mA or
10 V
Parameters described in this page can be accessed by:
DRI- > CONF > FULL > I_O- > AI1-
