BONFIGLIOLI Agile Applications Manual

VPLC / PLC 11308/10
5.7.1.2 [402] Write current parameter
Type Function Type Function
I1 % input value 1 O1 b I1[A]
I2 b Delete buffer O2 b inverted output = -1
I3 b Write release P1 i Parameter number
I4 b
Wait until writing
is finished
P2 i Data set (0 … 9) or index
Description:
The input value is converted from percent to A and written as int parameter.
]A[1I[ % ]1I →
123.45% = 123.45 A
5.7.1.3 [403] Write voltage parameter (eff.)
Type Function Type Function
I1 % input value 1 O1 b
]V[1I[ % ]1I →
I2 b Delete buffer O2 b inverted output = -1
I3 b Write release P1 i Parameter number
I4 b
Wait until writing
is finished
P2 i Data set (0 … 9) or index
Description:
The effective value at the input is converted from percent to V and written as int parameter.
] V [ 1 I[ % ] 1 I
→
123.45% = 123.45 V
08/10 VPLC / PLC 113
