VPLC / PLC 08/10146
146 VPLC / PLC 08/10
7.3 Signals for digital outputs of device
The following output signals of the can be assigned to the digital outputs of the frequency in-
verter.
Operation mode Function
0 - Off Digital output is switched off
80 - PLC output buffer 1
Digital output signal of an instruction. Signal source "2401 -
PLC output buffer 1" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2401.
81 - PLC output buffer 2
Digital output signal of an instruction. Signal source "2402 -
PLC output buffer 2" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2402.
82 - PLC output buffer 3
Digital output signal of an instruction. Signal source "2403 -
PLC output buffer 3" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2403.
83 - PLC output buffer 4
Digital output signal of an instruction. Signal source "2404 -
PLC output buffer 4" is the output signal. This signal source
contains the output value of the instruction assigned to signal
source 2404.
100 to 183 Operation modes inverted (LOW active).
7.4 Signals for analog outputs of device
Via a multifunction output, the values of analog instructions can be output.
The following output signals of the function table can be assigned to the analog outputs.
Operation mode Function
61 -
Abs. value PLC
outp. percent 1
Analog output signal of an instruction as an absolute value. Signal
source "2521 - PLC output percent 1" is the output signal. This sig-
nal source contains the output value of the instruction assigned to
signal source 2521.
62 -
Abs. value PLC
outp. percent 2
Analog output signal of an instruction as an absolute value. Signal
source "2522 - PLC output percent 2" is the output signal. This sig-
nal source contains the output value of the instruction assigned to
signal source 2522.
161 -
PLC outp. per-
cent 1
Analog output signal of an instruction. Signal source "2521 - PLC
output percent 1" is the output signal. This signal source contains
the output value of the instruction assigned to signal source 2521.
162 -
PLC outp. per-
cent 2
Analog output signal of an instruction. Signal source "2522 - PLC
output percent 2" is the output signal. This signal source contains
the output value of the instruction assigned to signal source 2522.
