7.2 Actual values of analog functions
The following parameters indicate the actual values
−
of the four indices of the analog input buffer.
− of the four signal sources of the analog output buffer (in the case of parameterization using
the function table, the signal sources assigned to parameters
PLC target output 1 1350 or
PLC target output 2 1351).
Parameters No. Parameters No.
PLC actual frequency value from
P.1379
1400
PLC actual output current value
251x
1407
PLC actual current value from P.1380
1401
PLC actual output percentage
252x
1408
PLC actual percentage from P.1381
1402
PLC actual output voltage eff.
253x
1409
PLC actual voltage eff. from P.1382
1403
PLC actual output voltage sp. 253x
1410
PLC actual voltage sp. from P.1382
1404
PLC actual output general 255x
1411
PLC actual value general from
P.1383
1405
PLC actual value flag 256x
1412
PLC actual output frequency 250x
1406
Example: Actual value display, parameterization using the function table
Function Table Input Buffer analog
FT-input buffer frequency 1379
Vtable
Index 2
10 - Stator Frequency
FT-target output 1 1350 2504 - FT-Output Frequency 4
FT-Act. Val. Freq. from P.1379 1400
VPlus
0.00 Hz
Parameter
15.00 Hz 0.00 Hz 0.00 Hz
FT-Act. Val.Outp. Freq. 250x 1406
0.00 Hz 0.00 Hz 0.00 Hz 5.00 Hz
Function Table Index 1
The parameter names may differ from the names shown, depending on the device series. The
parameter numbers are identical:
