4.2.1 Chronological behavior
The setup of P1 and P2 affects the following instructions:
40 … 42 / 140 … 142
Delay
50 … 52 / 150 … 152
60 … 62 / 160 … 162
Monoflop
70 … 72 / 170 … 172
80 … 82 / 180 … 182 Clock generator
The units of P1 and P2 may be set to milliseconds [ms], seconds [s] or minutes [min]. The unit
of the entered value depends on the instruction.
Note:
Time set for P1 and P2,
− are limited internally to the maximum value of 24 days
− are not continued when the frequency is switched off and on again. The sequence is res-
tarted from the beginning after re-activation.
4.2.2 Jump target
The evaluation of P1 and P2 affects the following instruction:
100 Jump function
Description Min. Max.
P1 1 32
P2 1 32
4.2.3 Overview table
The meaning of the settings for P1 and P2, depending on the selection of the application is
summarized in the following table.
Instruction P1 P2
40 -
140 -
delay ms
(retriggerable)
delay pos. edge [ms] delay neg. edge [ms]
41 -
141 -
delay s
(retriggerable)
delay pos. edge [s] delay neg. edge [s]
42 -
142 -
delay min
(retriggerable)
delay pos. edge [min] delay neg. edge [min]
50 -
150 -
delay ms
(non-retriggerable)
delay pos. edge [ms] delay neg. edge [ms]
51 -
151 -
delay s
(non-retriggerable)
delay pos. edge [s] delay neg. edge [s]
52 -
152 -
delay min
(non-retriggerable)
delay pos. edge [min] delay neg. edge [min]
60 -
160 -
Monoflop ms (retriggerable) ON time [ms] ignore edge time [ms]
61 -
161 -
Monoflop s (retriggerable) ON time [s] ignore edge time [s]
62 -
162 -
Monoflop min (retriggerable) ON time [min] ignore edge time [min]
70 -
170 -
Monoflop ms (non-retriggerable) ON time [ms] ignore edge time [ms]
71 -
171 -
Monoflop s (non-retriggerable) ON time [s] ignore edge time [s]
