VPLC / PLC 08/10156
156 VPLC / PLC 08/10
9.2 Parameters of function table
The following parameters are needed only for parameterization using the function table.
PLC functions
No. Description Unit Setting range
Factory
setting
Chap-
ter
1341
PLC write index (PLC
table item)
- 0 … 65 1
6.1.1
1342
PLC read index (PLC
table item)
- 0 … 65 1
6.1.1
1343
PLC instruction - Selection
0 - Off
(last
table item)
6.3
1344
PLC input 1 - Selection 7 – FALSE
6.3
1345
PLC input 2 - Selection 7 – FALSE
6.3
1346
PLC input 3 - Selection 7 – FALSE
6.3
1347
PLC input 4 - Selection 7 – FALSE
6.3
1348
PLC parameter 1
Depend-
ing on
instruction
0 … 65535 10
4.2, 5.1
1349
PLC parameter 2 0 … 65535 10
4.2, 5.1
1350
SPS target output 1 - Selection
0 - Output
not usable
globally
6.3
1351
SPS target output 2 - Selection
0 - Output
not usable
globally
6.3
1352 PLC commentary - 16 characters -
6.3
PLC functions input buffer
1360
PLC write index (PLC
table item)
- 0 … 33 1
6.1.2
1361
PLC read index (PLC
input buffer)
- 0 … 33 1
6.1.2
1362
PLC input buffer - Selection 7 - Off
6.1.2
PLC functions input buffer analog
1377
PLC write index (PLC
input analog)
- 0 … 9 1
6.1.3
1378
PLC read index (PLC
input analog)
- 0 … 9 1
6.1.3
1379
PLC input buffer fre-
quency
- Selection 9 - zero
6.1.3
1380
PLC input buffer cur-
rent
- Selection 9 - zero
6.1.3
1381
PLC input buffer per-
cent
- Selection 9 - zero
6.1.3
1382
PLC input buffer vol-
tage
- Selection 9 - zero
6.1.3
1383
SPS input buffer gen-
eral source
- 0 2 147 483 647 9
6.1.3
1384
Numerator general
source input 1383
% -327.68 … 327.67 100.00
6.1.3
1385
Denominator general
source input 1383
% 0.01 … 327.67 100.00
6.1.3
1386
Numerator general
source output 2551
% -327.68 … 327.67 100.00
6.1.3
1387
Denominator general
source output 2551
% 0.01 … 327.67 100.00
6.1.3
1388
PLC fixed frequency
value
Hz -999.99 … 999.99 50.00
6.1.3
