2.3.2 Other menu commands
Function Menu command
Save a VPLC file under a new file name.
File Æ Save as
Export a VPLC file to a VCB file. The VCB file con-
taining the parameter values created by the PLC
functions can be edited in VPlus.
File Æ Export to VCB
Opens the print setup window. Prints the editor
area.
File Æ Print
Adjust the page size of the editor.
File Æ Pa
e setup
View the page as it will be when printed.
File Æ Print preview
Select all objects in editor.
Edit Æ Select all
Opens the VPLC setup window:
Edit Æ VPLC setup
Interface: VPlus (auto) is displayed
if VPLC was started in
VPlus (default setting).
COM: The available in-
terfaces are displayed.
Only if VPLC is started
without VPlus.
Language: Select the language of
the user environment
and the menu com-
mands.
Apply texts from
inverter:
e selected at
the frequency inverter is
applied to the signal
sources in VPLC.
Show parameter values: The values of fields P1
and P2 of the function
block settings will be
displayed below the
function block.
Sheet size: Adjust the page size of
the editor.
The changes made with VPLC are deleted in the
frequency inverter and reset to the default set-
tings.
PLC Æ Delete
Apply the function block program to parameter
values and download them to the frequency inver-
ter. While edited in the editor, the function block
program is not changed in the frequency inverter.
Changes will only be applied to the frequency in-
verter by this command.
PLC Æ
ranslate and download to fre-
quency inverter
Note:
Working on the sheet doesn’t change the program inside the frequency inverter. Only via the
Download Command the changes of the PLC program are loaded to the frequency inverter.
