9 List of parameters
The parameter list is structured according to the menu branches of the control unit. The para-
meters are listed in ascending numerical order. A headline (shaded) can appear several times,
i.e. a subject area may be listed at different places in the table. For better clarity, the parame-
ters have been marked with pictograms:
The parameter is available in the four data sets.
The parameter value is set by the SETUP routine.
This parameter cannot be written when the frequency inverter is in operation.
This parameter can only be written in setting FT-Runmode 1399 = "0 - Stop".
I
FUN,
U
FUN,
P
FUN
: Nominal values of frequency inverter, ü: Overload capacity of frequency inverter
Note:
In the KP500 control unit, parameter numbers > 999 are represented in hexadecimal form
(999, A00 … B54 … C66 …).
9.1 Actual values
Table of functions
No. Description Unit Display range Chapter
1356 PLC actual values function -
X01:…. .. 01:… ..to
X32:!!!! !! 32:!!!! !!
7.1
1357 PLC actual values output buffer -
…. …. …. …. to
!!!! !!!! !!!! !!!!
7.1
1358 PLC Actual values input buffer -
…. …. …. …. to
!!!! !!!! !!!! !!!!
7.1
1400 PLC actual frequency value from P.1379 Hz 0.00 … 999.99
7.2
1401 PLC actual current value from P.1380 A 0.0 … I
max
7.2
1402 PLC actual percentage from P.1381 % -200 … 200
7.2
1403 PLC actual voltage eff. from P.1382 V 0.0 … U
FUN
7.2
1404 PLC actual voltage sp. from P.1382 V 0.0 … U
FUN
7.2
1405 PLC actual value general from P.1383 - -32767 … 32767
7.2
1406 PLC actual output frequency 250x Hz -999.99 … 999.99
7.2
1407 PLC actual output current value 251x A -I
max
… I
max
7.2
1408 PLC actual output percentage 252x % -200 … 200
7.2
1409 PLC actual output voltage eff. 253x V 0.0 … U
FUN
7.2
1410 PLC actual output voltage sp. 253x V 0.0 … U
FUN
7.2
1411 PLC actual output general 255x - -32767 … 32767
7.2
1412 PLC actual value flag 256x % -327.67 … 327.67
7.2
