7 Actual values, output signals and messages
7.1 Actual values of digital functions
Actual values of input and output buffers
− The actual values of the global outputs 2401 to 2416 - "PLC output buffer" are indicated by
parameter
PLC actual values output buffer 1357.
− The actual values of the global inputs 2001 to 2016 - "PLC input buffer" are indicated by
parameter
PLC actual values input buffer 1358.
Example
e.g. display: ".… !.!. !!!! .!.."
. . . . ! . ! . ! ! ! ! . ! . .
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16
"." = FALSE
"!" = TRUE
In the example, the following is TRUE:
2405 - PLC output buffer 5
2407 - PLC output buffer 7
2409 - PLC output buffer 9
2410 - PLC output buffer 10
2411 - PLC output buffer 11
2412 - PLC output buffer 12
2414 - PLC output buffer 14
