VPLC / PLC 11708/10
5.7.2.3 [423] Read voltage parameter (eff.)
Type Function Type Function
I1 - - O1 % Parameter value [V]
I2 - - O2 % inverted output = -1
I3 b Release read access P1 i Parameter number
I4 - - P2 i Data set (0 … 4)/index
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a voltage value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.4 [424] Read voltage parameter (peak)
Type Function Type Function
I1 - - O1 % Parameter value [V]
I2 - - O2 % inverted output = -1
I3 b Release read access P1 i Parameter number
I4 - - P2 i Data set (0 … 4)/index
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a voltage value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.5 [425] Read percent parameter
Type Function Type Function
I1 - - O1 % Parameter value [%]
I2 - - O2 % inverted output = -1
I3 b Release read access P1 i Parameter number
I4 - - P2 i Data set (0 … 4)/index
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a percent value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
5.7.2.6 [426] Read position parameter
Type Function Type Function
I1 - - O1 %
Position
value
Low word
I2 - - O2 % High word
I3 b Release read access P1 i Parameter number
I4 - - P2 i Data set (0 … 4)/index
Description:
The function reads the value of the parameter set up in P1 "Parameter number" and P2 "Data
set/index". The value is converted to a position value. Via Input I3 read access is enabled.
I3 = 0: No read access.
I3 = 1: The parameter value is read. The instruction is executed until the value is read.
08/10 VPLC / PLC 117
