Write index and read index for FT-instructions in function table for parameters:
1343, 1344, 1345, 1346, 1347, 1348, 1349, 1350, 1351, 1352
FT-instruction 1343
FT-target output 1 1350
FT-target output 2 1351
Parameter D-Satz 0
FT-input 3 1346
FT-input 2 1345
FT-input 1 1344
FT-input 4 1347
FT-Parameter 1 1348
FT-Parameter 2 1349
2
FT-Write index (FT-table item) 1341
2
FT-Read index (FT-table item) 1342
VPlus
FT-actual values output buffer 1357
FT-actual values input buffer 1358
AND
...
...
...
...
...
...
...
...
...
...
FT-instruction 1343
FT-target output 1 1350
FT-target output 2 1351
Funktionentabelle
Index 2
FT-input 3 1346
FT-input 2 1345
FT-input 1 1344
FT-input 4 1347
FT-Parameter 1 1348
FT-Parameter 2 1349
VTable
1 - AND
...
...
...
...
...
...
...
...
Index 1
2 - OR
...
...
...
...
...
...
...
...
6.1.2 Write index and read index for the digital input buffer
Via the write and read indices, the index of the "Function table: input buffer" to be read or writ-
ten is specified.
Write index and read index for parameterization and reading of "Function table:
input buffer via software VPlus
The "Function table: input buffer" can be parameterized in the user interface VPlus or in the
function table VTable. In the user interface VPlus, an index of the input buffer can be created
via parameter
FT-Write Index (FT Input Buffer) 1360. The chosen index corresponds to a col-
umn in the "Function table: Input buffer" and thus an index of parameter
FT-Input Buffer
1362. The setting (selection of signal source or digital input) of parameter FT-Input Buffer
1362 is applied to the set index of "Function table: input buffer". Via parameter FT-Read In-
dex (FT-Input Buffer)
1361, the values of a selected index can be read from the "Function
table: input buffer".
Parameters Setting
No. Description Min. Max. Fact. sett.
1360 FT-Write Index (FT-input buffer) 0 33 1
1361 FT-Read Index (FT-input buffer) 0 33 1
Settings for fixed parameterization
(non-volatile):
Settings for non-fixed parameterization
(volatile):
0: all input buffers in EEPROM 17: all input buffers in RAM
1 … 16: individual input buffer in EEPROM 18 … 33: individual input buffer in RAM
Note:
The settings "0" or "17" for FT Write Index (FT input buffer) 1360 change all values of an
input buffer in the EEPROM or RAM.
In the case of non-volatile storage (0..16), the changed values are still available when power
supply is switched on again.
In the case of volatile storage (17…33), the data is only stored in RAM. If the unit is switched
off, this data is lost and the data required are loaded from EEPROM.
Caution!
Writing of the EEPROM is restricted to approx. 1 million times. If this number is
exceeded, the device may be damaged.
