BONFIGLIOLI Agile Applications Manual

VPLC / PLC 08/10154
154 VPLC / PLC 08/10
Index 5 Index 6
FT instruction 1343
2 – OR 80 – Clock generator
FT input 1 1344
6 – TRUE 2003 - Input buffer 3
FT input 2 1345
7 – FALSE
7 – FALSE
FT input 3 1346
7 – FALSE
7 – FALSE
FT input 4 1347
7 – FALSE
7 – FALSE
FT-Parameter 1 1348
0 100
FT-Parameter 2 1349
0 100
FT-Target Output 1 1350
2401 FT-Output buffer 1 2403 FT-Output buffer 3
FT-Target Output 2 1351
2411 FT-Output buffer 11 0
FT Commentary 1352
Z3: 2401=1
Z3a: clock
Index 7 Index 8
FT instruction 1343
100 – Jump function 100 – Jump function
FT input 1 1344
2005 - Input buffer 5 6 – TRUE
FT input 2 1345
6 – TRUE 2003 - Input buffer 3
FT input 3 1346
6 – TRUE 6 – TRUE
FT input 4 1347
6 – TRUE 6 – TRUE
FT-Parameter 1 1348
9 6
FT-Parameter 2 1349
8 7
FT-Target Output 1 1350
0 0
FT-Target Output 2
1351 0 0
FT Commentary 1352
Z3 --> Z4 Z3 -> Z4
Index 9 Index 10
FT instruction 1343
2 – OR 100 – Jump function
FT input 1 1344
6 – TRUE 6 – TRUE
FT input 2 1345
7 – FALSE 2002 - Input buffer 2
FT input 3 1346
7 – FALSE
6 – TRUE
FT input 4 1347
7 – FALSE
6 – TRUE
FT-Parameter 1 1348
0 11
FT-Parameter 2 1349
0 10
FT-Target Output 1 1350
2410 FT-Output buffer 10 0
FT-Target Output 2 1351
2401 FT-Output buffer 1 0
FT Commentary 1352
Z4: 2410=1 Z4 --> Z5
Index 11 Index 12
FT instruction 1343
2 – OR 80 – Clock generator
FT input 1 1344
6 – TRUE 2003 - Input buffer 3
FT input 2 1345
7 – FALSE
7 – FALSE
FT input 3 1346
7 – FALSE
7 – FALSE
FT input 4 1347
7 – FALSE
7 – FALSE
FT-Parameter 1 1348
0 100
FT-Parameter 2 1349
0 100
FT-Target Output 1 1350
2401 FT-Output buffer 1 2404 FT-Output buffer 4
FT-Target Output 2 1351
2411 FT-Output buffer 11 0
FT Commentary 1352
Z5: 2401=1
Z5a: clock
Index 13 Index 14
FT instruction 1343
100 – Jump function 100 – Jump function
FT input 1 1344
2006 - Input buffer 6 6 – TRUE
FT input 2 1345
6 – TRUE 2003 - Input buffer 3
FT input 3 1346
6 – TRUE 6 – TRUE
FT input 4 1347
6 – TRUE 6 – TRUE
FT-Parameter 1 1348
3 12
FT-Parameter 2 1349
14 13
FT-Target Output 1 1350
0 0
FT-Target Output 2 1351
0 0
FT Commentary 1352
Z5 --> Z2 Z5 -> Z2
