Page #135 background image
Pin Assignment
Connection Signal Function
1 GND_shld Connection signal shields (internal shields)
2 A+ Track A analog positive
3 A- Track A analog negative
4 GND_Encoder Reference potential power supplies
5 B+ Track B analog positive
6 B- Track B analog negative
7 EncData+ Data transmission positive
A+TTL Track A TTL positive
8 EncData- Data transmission negative
A-TTL Track A TTL negative
9 R+ Reference track positive
10 R- Reference track negative
11 +12V Encoder supply 12V
12 +5V Encoder supply 5V
13 EncCLK+ Clock positive
B+TTL Track B TTL positive
14 EncCLK- Clock negative
B-TTL Track B TTL negative
15 Sense- Return of reference potential (Sense line)
VCC_Resolver Resolver supply
Connector
housing
Overall shield
Tab. 6-5: Pin Assignment
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 133/341
Rexroth IndraDrive CsDrive Systems with HCS01
Mounting and installation
