Equipment grounding conductor
Connect the equipment grounding conductor via thread M5 to the housing of
the device (identification mark ; tightening torque: 5 Nm). The M5×12
screw required for this purpose is part of the supplied accessories HAS09.
DC bus
Connect HLC01 to HCS01 with twisted lines: L+ to L+; L- to L-
Technical data of the connection point: See description of connection point
X77.
Arrangement
Place the HLC next to the most powerful drive controller of a drive system.
Operation
Mains Choke
Always operate the DC bus capacitor units together with the mains choke as‐
signed to the drive controller (see chapter 7.3.2 "Mains voltage" on page
233).
Special case "HCS01.1E-W0018-_-03" (in the technical data, no mains choke
has been assigned to this drive controller):
Use the mains choke "HNL01.1E-1000-N0012-A-500-NNNN".
DC bus coupling
Information on DC bus coupling: See chapter "DC Bus Capacitor Unit" on
page 111
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 311/341
Rexroth IndraDrive CsDrive Systems with HCS01
Cables, accessories, additional components
