Documentations
Drive systems, system components
Title
Rexroth IndraDrive …
Type of documentation
Document typecode
1)
DOK-INDRV*-…
Material number
R911…
Cs drive systems Project Planning Manual HCS01******-PRxx-EN-P 322210
1) In the document typecodes, "xx" is a placeholder for the current
edition of the documentation (e.g.: PR01 is the first edition of a
Project Planning Manual)
Tab. 1-12: Documentations – drive systems, system components
Motors
Title
Rexroth IndraDyn …
Type of documentation
Document typecode
1)
DOK-MOTOR*-…
Material number
R911…
A Asynchronous Motors MAD / MAF Project Planning Manual MAD/MAF****-PRxx-EN-P 295781
H Synchronous Kit Spindle Motors Project Planning Manual MBS-H******-PRxx-EN-P 297895
L Synchronous Linear Motors Project Planning Manual MLF********-PRxx-EN-P 293635
L Ironless Linear Motors MCL Project Planning Manual MCL********-PRxx-EN-P 330592
S Synchronous Motors MKE Project Planning Manual MKE*GEN2***-PRxx-EN-P 297663
S Synchronous Motors MSK Project Planning Manual MSK********-PRxx-EN-P 296289
S Synchronous Motors MSM Data Sheet MSM********-DAxx-EN-P 329338
S Synchronous Motors MS2N Project Planning Manual MS2N*******-PRxx-EN-P 347583
T Synchronous Torque Motors Project Planning Manual MBT********-PRxx-EN-P 298798
1) In the document typecodes, "xx" is a placeholder for the current
edition of the documentation (e.g.: PR01 is the first edition of a
Project Planning Manual)
Tab. 1-13: Documentations – motors
Cables
Title Type of documentation
Document typecode
1)
DOK-CONNEC-…
Material number
R911…
Rexroth Connection Cables
IndraDrive and IndraDyn
Selection Data CABLE*INDRV-CAxx-EN-P 322949
1) In the document typecodes, "xx" is a placeholder for the current
edition of the documentation (e.g.: CA03 is the third edition of
the documentation "Catalog")
Tab. 1-14: Documentations – cables
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 25/341
Rexroth IndraDrive CsDrive Systems with HCS01
System presentation
