Bosch Rexroth IndraDrive CsDrive System with HCS01 - Tions

Country of use: international except for USA/Canada
Fuse I
N
[A] Current carrying ca‐
pacity (× 0.87) I
Z(40)
[A]
Cross section A [mm
2
]
Installation type E
1 × 2 × 3 ×
315 785.61 3 x 240
400 908.02 3 x 300
Tab. 11-3: Line cross sections and fuses, E according to EN 60204-1:2006, Ta‐
ble 6, for 150mm² and more DIN IEC 60364-5-52:2004, Table B.
52-10
USA/Canada; installation type E
Country of use: USA/Canada
Fuse I
N
Current carry‐
ing capacity I
Z
[A]
Cross section A
Installation type E
1 × 2 × 3 × 4 ×
2 1.6 14 AWG
4 3.3 14 AWG
6 5 14 AWG
10 8.3 14 AWG
16 13 14 AWG
20 15 14 AWG
25 20 12 AWG
40 30 10 AWG
70 50 8 AWG
80 65 6 AWG
100 85 4 AWG
110 100 3 AWG
125 115 2 AWG
150 130 1 AWG
175 150 1/0 AWG
200 175 2/0 AWG
225 200 3/0 AWG
250 230 4/0 AWG
300 255 250 kcmil
300 285 300 kcmil
350 310 350 kcmil
350 335 400 kcmil
400 380 500 kcmil
450 420 600 kcmil
600 460 700 kcmil
