8.2 Accessories
8.2.1 Mounting and connection accessories (HAS09)
Use
The accessories contain:
● Screws for mounting the component
● Screws for connecting the equipment grounding conductor
● Parts for shield connection of cables (plates, screws)
● Parts for shield connection of module bus cables (heat shrink tubing,
copper tape)
● Adhesive labels with notes on safety in the English and French languag‐
es. Place the adhesive labels clearly visibly at the component or in the
immediate vicinity of the component, if the adhesive labels existing at
the component are hidden by neighboring components.
The accessories are part of the standard scope of supply.
Assignment
Accessories Component
HAS09.1-001-NNN-NN HCS01.1E-W0003 … W0028
HAS09.1-003-NNN-NN HCS01.1E-W0054
HAS09.1-004-NNN-NN HLC01.2; HLR01.2N
Tab. 8-4: HAS09 and HCS01
DOK-INDRV*-HCS01******-PR05-EN-P Bosch Rexroth AG 251/341
Rexroth IndraDrive CsDrive Systems with HCS01
Cables, accessories, additional components
