HAP01 ↔ HCS01 assignment
Control panel Drive controller
HAP01.1A HCS01.1E-W****-*-**-A-CC (ADVANCED)
HCS01.1E-W****-*-**-A-ET (ADVANCED)
HCS01.1E-W****-*-**-B-ET (BASIC)
1)
HCS01.1E-W****-*-**-E-S3 (ECONOMY)
1)
HAP01.1N HCS01.1E-W****-*-**-B-ET (BASIC)
HCS01.1E-W****-*-**-E-S3 (ECONOMY)
1) Requires firmware MPx-20 or higher
Tab. 1-10: HAP01 ↔ HCS01 assignment
● chapter "Standard control panel HAP01.1N" on page 230
● chapter "ADVANCED Control Panel HAP01.1A" on page 231
Firmware
Firmware types
ECONOMY
● FWA-INDRV*-MPE-16VRS-D5-x-NNN-NN
● FWA-INDRV*-MPE-17VRS-D5-x-NNN-NN
● FWA-INDRV*-MPE-18VRS-D5-x-NNN-NN
● FWA-INDRV*-MPE-20VRS-D5-x-NNN-NN
BASIC
● FWA-INDRV*-MPE-18VRS-D5-x-NNN-NN
● FWA-INDRV*-MPB-16VRS-D5-x-xxx-xx
● FWA-INDRV*-MPB-17VRS-D5-x-xxx-xx
● FWA-INDRV*-MPB-18VRS-D5-x-xxx-xx
● FWA-INDRV*-MPB-20VRS-D5-x-xxx-xx
ADVANCED
● FWA-INDRV*-MPC-17VRS-D5-x-xxx-xx
● FWA-INDRV*-MPC-18VRS-D5-x-xxx-xx
● FWA-INDRV*-MPC-20VRS-D5-x-xxx-xx
See also chapter "Firmware types" on page 44
For detailed information, see the Functional Description of the firmware
used (index entry "Overview of functions/functional packages").
