Short type designation 1 2 3 4 5 6 7 8 9
1
0 1 2 3 4 5 6 7 8 9
2
0 1 2 3 4 5 6 7 8 9
3
0 1 2 3 4 5 6 7 8 9
4
0
Example: H C S 0 1 . 1 E - W 0 0 1 3 - A - 0 2 - E - S 3 - E C - N N - N N - N N - F W
① ② ③④ ⑤ ⑥ ⑦ ⑧ ⑨ ⑩ ⑪ ⑫ ⑬ ⑭ ⑮
⑪ Interface 1:
EC = Multi-encoder interface
⑫
Interface 2
2)
:
CN = CANopen
DA = Digital/analog I/O extension
EC = Multi-encoder interface
EP = Engineering port
EM = Encoder emulation
ET = Multi-Ethernet
NN = Not equipped
PB = PROFIBUS
⑬
Interface 3
2) 3)
:
L3 = STO (Safe Torque Off)
L4 = STO (Safe Torque Off) and SBC
NN = Not equipped
S4 = Safe Motion
S5 = Safe Motion
SB = Safe Motion Bus
⑭ Other design:
NN = None
⑮ Firmware:
FW = With control panel, firmware has to be ordered separately
NW = Without control panel, without firmware
1) See table "Possible combinations of maximum current and
mains connection voltage"
2) See table "Possible combinations of options"
3) The L3, S4, S5 and SB interfaces guarantee both the function
and the certification
Tab. 1-6: Type code HCS01
Possible combinations of maximum current and mains connection voltage:
Mains connection voltage [V] Maximum current [A]
3 5 6 8 9 13 18 28 54
3 × AC 110 … 230 ✓ – ✓ – ✓ ✓ ✓ – –
3 × AC 200 … 500 – ✓ – ✓ – – ✓ ✓ ✓
Tab. 1-7: Possible combinations of maximum current and mains connection
voltage
