Notes on installation
When using NFE02 or NFD03 mains filters at mains grounded via
outer conductor, install an isolating transformer between mains
and mains filter.
Selecting the mains filter
The specified mains filter types are exclusively suited for TN and
TT mains.
The EMC limit values relate to line-based noise emission in the
frequency range of 0.15 … 30 MHz on the mains connection
lines.
HCS01.1E-W0005, -W0008, -W0018-A-03, -W00028, -W00054
Nominal voltage of mains filter: 3 × 400 V
Clock frequency
[kHz]
Leakage capacitance (motor + ca‐
ble)
[nF]
Mains filters EMC limit value class to be ach‐
ieved
(IEC / EN 61800-3)
4; 8 < 100
NFD03.1
1)
C2
12; 16 < 30
1) Leakage capacitances > 100 nF overload the mains filter (over‐
temperature, saturation phenomenon)
Tab. 4-36: Mains filter; 3 × 400 V
HCS01.1E-W0005, -W0008, -W0018-A-03, -W00028, -W00054
Nominal voltage of mains filter: 3 × 400 … 500 V
Clock frequency
[kHz]
Leakage capacitance (motor + ca‐
ble)
[nF]
Mains filters EMC limit value class to be ach‐
ieved
(IEC / EN 61800-3)
4; 8 < 70 FN3258H (Schaffner) C2
4; 8 70 < … < 100 C3
12; 16 < 20 C2
12; 16 20 < … < 50 C3
Tab. 4-37: Mains filter; 3 × 400 … 500 V
Bosch Rexroth AG DOK-INDRV*-HCS01******-PR05-EN-P98/341
Rexroth IndraDrive CsDrive Systems with HCS01
Combining the individual components
