Maximum mains con‐
nection voltage of
mains 50…60 Hz
U
N
Nominal
mains
current
I
nenn
(1)
Number
of pha‐
ses
Mains filter type Terminal connectors (3) Power
dissipa‐
tion ap‐
prox.
Weig
ht
Type of
construc‐
tion
AC 230V +10% 7,5 1 NFE
02.1-230-008
4 (3) 6 (3) AWG 10 7,2 1,1 Vertical
NFD Three-phase filter
NFE Single-phase filter
(1) Mains-side maximum continuous current at 45 °C ambient tem‐
perature
(2) Only use for interference suppression of the power supply unit
NTM
(3) For the equipment grounding conductor, connect a conductor
cross section of 10 mm2 by means of terminal pin or ring cable
lug
Tab. 8-27: Technical data
Operating frequency From 0-60 Hz at 45 °C
Power dissipation
Measured 2 or 3 × RI
2
Nenn DC
Temperature range -25 … +85 ℃
Overload 1.5 × I
Nenn
1 minute per hour or 4 × I
Nenn
for 10 s
Effective attenuation Frequency range 0.15-30 MHz
Saturation behavior Reduction of filter attenuation by 6 dB at 2.5-fold to 3-fold
nominal current
Test voltage L/N → PE or L → PE: 2000 V, 50 Hz, 2 s at 25 °C
L/ N → L: DC 1,100 V, 2 s at 25 °C
Current reduction in
the case of overtem‐
perature
See formula for reduction in chapter "Calculations"
Leakage current at
50 Hz
Symmetrical three-phase operation: Typ. 30 mA
Single-phase operation or in the case of tripped fuses of a
phase: Typ. 175 … 190 mA
Degree of protection IP 20
Tab. 8-28: Technical Data
