4.3.3 Firmware
Firmware and device types
Device type Firmware
HCS01.1E-W00**-A-0*-E-S3 (ECONOMY) FWA-INDRV*-MPE-16VRS-D5-x-NNN-NN
FWA-INDRV*-MPE-17VRS-D5-x-NNN-NN
FWA-INDRV*-MPE-18VRS-D5-x-NNN-NN
FWA-INDRV*-MPE-20VRS-D5-x-NNN-NN
HCS01.1E-W00**-A-0*-B-ET (BASIC) FWA-INDRV*-MPB-16VRS-D5-x-xxx-xx
FWA-INDRV*-MPB-17VRS-D5-x-xxx-xx
FWA-INDRV*-MPB-18VRS-D5-x-xxx-xx
FWA-INDRV*-MPB-20VRS-D5-x-xxx-xx
HCS01.1E-W00**-A-0*-A-CC (ADVANCED) FWA-INDRV*-MPC-17VRS-D5-x-xxx-xx
FWA-INDRV*-MPC-18VRS-D5-x-xxx-xx
FWA-INDRV*-MPC-20VRS-D5-x-xxx-xx
HCS01.1E-W00**-A-0*-A-ET (ADVANCED) FWA-INDRV*-MPC-20VRS-D5-x-xxx-xx
Tab. 4-4: Device types and firmware
Firmware types
Structure of the firmware type des‐
ignation
The type designation of the firmware consists of the following type code ele‐
ments:
Firmware
Base package of
variant ... Version Release
Lan‐
guage
Characteris‐
tic
Open-loop /
Closed-loop
Alternative
expansion
packages
Additive ex‐
pansion
packages
FWA-INDRV*- MPE- 16 VRS- D5- x- NNN- NN
17
18
20
FWA-INDRV*- MPB- 16 VRS- D5- x- xxx- xx
17
18
20
FWA-INDRV*- MPC- 17 VRS- D5- x- xxx- xx
18
20
Tab. 4-5: Basic structure of the firmware type designation
Function-specific abbreviations in
type designation of firmware
Base package (application and performance)
● MPE → Firmware with ECONOMY performance and ECONOMY func‐
tionality
